USB C power delivery sockets
Focus SB’s 13A switched 2 gang USB C Power Delivery socket outlets for charging phones and tablets and laptops is one of the fastest charging available in the UK market.
Featuring two USB ports, a 18W Type A and 45W Type C Power Delivery, both ports can be used simultaneously offering a combined output of 45W. Available in the following ranges with black or white inserts.
Contact us for further information or learn more about USB C power delivery on our blog.
Technical
Supply Voltage 250V AC
Socket Rating 13A
Output Combined A+C 45W
Type A & Type C 5-12V 18W 5V 3A, 9V 3A, 12V 2.25A, and 15V 1.8A
Output C Only 5V 3A, 9V 3A, 12V 3A, 15V 3A and 20V 2.25A
Protocols Supported Type A APPLE 2.4A, BC1.2, AFC, FCP, and QC3.0
Protocols Supported Type C APPLE 2.4A, BC1.2, PE2.0, AFC, FCP, SCP, QC3.0, PD3.0
USB A sockets
Focus SB’s 13A switched 2 gang USB A integrated socket outlets for charging phones and tablets, featuring two USB ports offering a combined charging rate of 3 amp via a 2.1 amp and a 1-amp socket (1 gang version 1.2 amp only).
Available with trimmed or trimless switches with black or white inserts.
Contact us for further information.
Technical
Port one rated 2.1 amp at 5V (also applies to single USB socket)
Port two rated 1 amp at 5V
Max output of 3.1 amp
Two 13-amp sockets 250v rated
CE and UKCA marked.
